Wheel skid steer loader

Wheel skid steer loader

Skid-steer loaders are also called skid-steer loaders, multi-functional engineering vehicles, and multi-functional engineering machines. It is a special wheeled chassis equipment that uses the linear speed difference of the wheels on both sides to achieve vehicle steering. It is mainly used in situations where the working site is small, the ground is uneven, and the work content changes frequently. It is suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residences, barns, livestock sheds, airport runways, etc. It can also be used as auxiliary equipment for large-scale engineering construction machinery.

Rated load(kg):380—1100kg Rated power(kw):18—74kw Operation weight(kg):2100—7500kg Self weight bucket (kg) :1200—4000kg Engine:Kubota, Cummins
  • Selling point
  • Configuration
  • Video Introduction
  • Relevant
  • Online message
We Accept:
Wheel skid steer loader

Skid-steer loaders are also called skid-steer loaders, multi-functional engineering vehicles, and multi-functional engineering machines. It is a special wheeled chassis equipment that uses the linear speed difference of the wheels on both sides to achieve vehicle steering. It is mainly used in situations where the working site is small, the ground is uneven, and the work content changes frequently. It is suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residences, barns, livestock sheds, airport runways, etc. It can also be used as auxiliary equipment for large-scale engineering construction machinery.

Rated load(kg):380—1100kg Rated power(kw):18—74kw Operation weight(kg):2100—7500kg Self weight bucket (kg) :1200—4000kg Engine:Kubota, Cummins
  • Wheel skid steer loader

  • ModelKJC-25KJC-35KJC-45KJC-60KJC-100
    Operating load(kg)3805007008501100
    Max Speed(km/h)7.810121298
    Rated flux(L/min)606062.57575
    High Flow Flux (L/min)////140
    Tire(track) model570x168.5-1510-16.512-16.512-16.5
    Rated power (Kw)18.237374574
    Fuel tank capacity (L)4060708090
    self weight bucket (kg)13702300270028003550
    Bucket capacity (m³)0.160.30.40.40.55
    Overall operating height (mm)35903300398040004070
    Height to bucket hinge pin (mm)26702725308031003280
    Height to top of cab (mm)18202000214021602160
    Height to bottom of level bucket(mm)23802558291329333140
    Without bucket length(mm)19452300264027502880
    Overall length with bucket(mm)25802950342034903580
    Dumping angle at maximum height(° )4040404040
    Dumping height(mm)18202050238024002500
    Dumping reach(mm)450790700750700
    Rollback o bucket on ground(° )3030303030
    Rollback of bucket at full height(° )104104104104104
    Wheelbase(mm)8018979919911115
    Ground clearance(mm)125140185205205
    Angle of departure(° )2220202020
    Front turning radius without bucket(mm)9711098116811981278
    Front tuning radius(mm)17301760195819582144
    Rear tuning radius(mm)10101296163017281857
    Rear axle to bumper (mm)610964110812081082
    Tread width (mm)7601080145015001500
    Width (mm)9001350172018801880
    Bucket width (mm)9001400174018801880
